Operating sequence of installation
Instruction handbook BUM 60 / BUS 60
Document No.: 5.01032.05 Baumüller Nürnberg GmbH
48
of 82
7.8
7.8 Operating sequence of installation
DANGER!
Risk of fatal injury from electrical current!
Electrically live parts are life-threatening.
Therefore:
m Make certain that the parts to be mounted (e.g. power supply cables) and the
mounting areas are de-energized for the entire duration of mounting the device.
h Lay all cables EMC-compatible.
h Connect cables (see ZConnection diagrams– from page 49).
(refer to the permissible torque)
The following steps must be carried out at installation:
1 Connect the motor via the terminals 1U2, 1V2, 1W2, PE. Attend to the in-phase connection
(rotational direction).
(refer to the permissible torque)
2 Connect the device via the power input terminals 1U1, 1V1 and 1W1 to the power choke
output - not necessary for BUS 60.
3 Connect the protective conductor to the terminal PE (a permanent PE connection is required
imperatively).
4 Connect the 24 V supply
(in case you consider UL 508 C: limit the current to 4 A).
5 Connect the controller (see operation manual controller)
