TAM00721 22
DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013
Three-phase-synchronous motor English
7.5 ECN1313 / EQN 1325
(encoder with EnDat 2.1-port from Heidenhain companies; M23, 17-polig)
Pin Signal
Ansicht auf Kontaktseite
der Gerätedose
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
Up
-
-
0V
-
-
Up
Clock
Clock inv.
0V
-
B+
B-
Data
A+
A-
Data inv.
Figure 6: pole assignment ECN 1313 / EQN 1325
