TAM00721 8
DSD-028 / DSD-036 / DSD2-028 / DSD2-036 04/2013
Three-phase-synchronous motor English
2.4 Technical Data
Type of drive permanent magnet three phase synchronous motor
Designs (EN 60034-7) IM B5 Horizontal installation position
IM V1 Vertical installation position, shaft end down
IM V3 Vertical installation position, shaft end up
Note: For installation acc. to IM V3 combined with IP 44 ensure protection against the
penetration of water and dirt.
Degree of protection (EN 60034-5) with consideration of the shaft duct
IP 44 Standard: without shaft sealing ring
IP 65 Optional: with shaft sealing ring
without consideration of the shaft duct
IP 65 Standard: without shaft sealing ring
Caution: All specified protection classes are only achieved in the event of completely
assembled plug connectors (mains and control connections).
Cooling method (EN 60034-6) IC 410 Standard: self-surface-cooled; no fan
Electrical connections (comp. Chapter 7) via angled (3x90°) pivotable mounting boxes.
Alignment Standard: axial, to N-side
Optional: on request
Main connection 8-pin connector
Standard: U V W + thermal sensor
Optional: brake
Control connection 12-pin Standard: Resolver
Option: absolute encoder
Option: encoder + thermal sensor
Option: Hiperface-port
17-pin Option: Endat 2.1
8 / 9-pin Option: Endat 2.2
Thermal motor protection (EN 60034-11) Thermal sensor KTY84/130 in stator winding
Winding insulation (EN 60034-1) Thermal class F(∆θ = 105 K)
Ambient temperature 0 °C to +40 °C (standard)
Altitude (EN 60034-1) ≤ 1.000 m above sea level (standard)
Rolling-contact bearings Standard: Ball bearing with long-term grease lubrication
Calculated bearing life L
H10
20.000 h (approximate value)
Vibration severity (EN 60034-14) standard: level A
on request: level
True running (DIN 42955) standard: N
on request: R (reduced)
Shake proof (EN 60068-2-6) radial: 3 g (10 Hz to 100 Hz)
axial: 1 g (10 Hz to 100 Hz); with brake 0,5 g
Holding brake Option
Speed actual value encoder Standard: 2-pole resolver (higher quality version on request)
Option: absolute encoder with Hiperface-port
Option: absolute encoder with EnDat-port
For further technical data, refer to our technical product list online at: www.baumueller.com under
Download and Technical documentation. If necessary, you can request the corresponding
documentation.
Attention!
If the electric motor supplied is not a standard type as per the technical documentation or if special
contractual arrangements have been made, there may technical differences to these Commissioning and
Maintenance Instructions. In this case request the related technical supplements.
