Parameter Description Factory setting
DHW management
(
DP051)
ECO mode: use of the heat pump only. Comfort mode: use of the heat pump
and backup energy sources:
ECO (Only HP): use of the heat pump only
Comfort (HP+Boiler): use of the heat pump and back-ups
ECO (Only HP)
Hysteresis DHW
(
DP120)
Hysteresis temperature relative to the DHW temperature setpoint
Can be set from 0 °C to 40 °C
15
Tab.72 Adv. Parameters menu
Parameter Description Factory setting
Delay
StartBackupDHW
(
DP090)
Electrical back-up start-up time delay for domestic hot water.
Can be set from 0 to 120 min
90 min
Delay stop
BackupDHW (DP100)
Electrical back-up shutdown time delay for domestic hot water.
Can be set from 0 to 120 min
2 min
Delay
BackupStageDHW
(DP110)
Electrical back-up second stage start-up time delay for domestic hot water.
Can be set from 0 to 255 min
5 min
DHW backup type
(DP334)
Backup type used for domestic hot water production:
Indoor Unit
: indoor unit electrical back-ups
DHW Tank
: DHW tank electrical back-ups
IDU/DhwTank Cooling: Indoor unit electrical back-ups in winter/DHW tank
electrical back-ups in cooling mode
Indoor Unit
9.4.3 Installation Setup > CIRCA1/CIRCB1/DHW1/CIRCC1/
CIRCAUX1 > Parameters, counters, signals >
Depending on the installation configuration, only certain circuits are
available. The CIRCA1 \ CIRCB1 \ DHW1 \ CIRCC1 \ CIRCAUX1 circuits
are on the SCB-10 PCB.
Tab.73 Correspondence between the parameters and the circuits
CPxx0
parameters ending in 0 correspond to the CIRCA1 circuit
CPxx1
parameters ending in 1 correspond to the CIRCB1 circuit
CPxx2
parameters ending in 2 correspond to the DHW1 circuit
CPxx3
parameters ending in 3 correspond to the CIRCC1 circuit
CPxx4
parameters ending in 4 correspond to the CIRCAUX1 circuit
9 Settings
7762758 - v05 - 19082020 69
