DUCT
LSGND25-XM
LSGND35-XM
LSGND50-XM
Cooling capacity nom.(min.-max.) (kW)
2,60 (1,50-3,55)
3,60 (1,71-3,85)
5,10 (2,50-5,80)
Heating capacity nom.(min.-max.) (kW)
2,90 (1,70-3,65)
4,00 (1,90-3,92)
5,80 (2,84-6,40)
Air flow volume (m3/h) H/M/L
600/450/380
680/560/450
860/660/600
Sound pressure dB(A) H/M/L
35/31/28
38/34/31
42/38/36
Sound power dB(A)
53
53
55
Nominal available static pressure (Pa)
10
10
10
Dimensions width/height/depth (mm)
700x200x470
700x200x470
1000x200x470
Weight (kg)
18,5
18,5
24
Liquid piping diameter (inch/mm)
1/4"/6,35
1/4"/6,35
1/4"/6,35
Gas piping diameter (inch/mm)
1/2"/12,7
1/2"/12,7
1/2"/12,7
CASSETTE
LSGNK25-XM
LSGNK35-XM
LSGNK50-XM
Body name
LSGBK25-XM
LSGBK35-XM
LSGBK50-XM
Panel name
PKR50
PKR50
PKR50
Cooling capacity nom.(min.-max.) (kW)
2,80 (1,50-3,55)
3,60 (1,70-3,70)
5,00 (2,50-5,60)
Heating capacity nom.(min.-max.) (kW)
3,00 (1,60-3,81)
3,90 (2,03-4,42)
5,60 (3,03-7,03)
Air flow volume (m3/h) H/M/L
700/600/530
700/600/530
700/600/530
Sound pressure dB(A) H/M/L
45/41/35
45/41/35
45/41/35
Sound power dB(A)
56
56
56
Body dimensions width/height/depth (mm)
570x570x260
570x570x260
570x570x260
Panel dimensions width/height/depth (mm)
650x650x55
650x650x55
650x650x55
Body weight (kg)
18
18
18
Panel weight (kg)
2,2
2,2
2,2
Liquid piping diameter (inch/mm)
1/4"/6,35
1/4"/6,35
1/4"/6,35
Gas piping diameter (inch/mm)
1/2"/12,7
1/2"/12,7
1/2"/12,7
FLOOR/CEILING
LSGNC25-XM
LSGNC35-XM
LSGNC50-XM
Cooling capacity nom.(min.-max.) (kW)
2,80 (1,50-3,55)
3,60 (1,70-3,70)
5,30 (2,50-5,60)
Heating capacity nom.(min.-max.) (kW)
3,00 (1,60-3,81)
3,90 (2,03-4,42)
5,80 (3,03-7,03)
Air flow volume (m3/h) H/M/L
750/600/500
750/600/500
850/700/600
Sound pressure dB(A) H/M/L
39/36/30
39/36/30
45/42/40
Sound power dB(A)
55
55
59
Dimensions width/height/depth (mm)
929x660x205
929x660x205
929x660x205
Weight (kg)
26,0
26,0
26,0
Liquid piping diameter (inch/mm)
1/4"/6,35
1/4"/6,35
1/4"/6,35
Gas piping diameter (inch/mm)
1/2"/12,7
1/2"/12,7
1/2"/12,7
