Baxi JSGNW - Duct [Lsgnd(25;35;50)-XM]

5.2.2. DUCT [LSGND(25/35/50)-XM]
Installation space
Please be sure to meet the following installation space requirements when selecting the
installation site:
Location of the hosting bolt
Model
A
B
C
D
E
F
LSGND(25/35)-XM
532
700
684
734
383
470
LSGND50-XM
832
1000
977
1048
383
470
Duct installation
There are two installation methods of duct, as follows:
19
