3.1. OUTDOOR UNITS
MULTI OUTDOOR UNITS
LSGT40-2M
LSGT50-2M
LSGT60-3M
LSGT70-3M
LSGT100-4M
LSGT125-5M
Combinability
2x1
2x1
3x1
3x1
4x1
5x1
Type
ULTRA DC
Inverter
ULTRA DC
Inverter
ULTRA DC
Inverter
ULTRA DC
Inverter
ULTRA DC
Inverter
ULTRA DC
Inverter
Cooling capacity nom.(min.-max.)
(kW)
4,10
(1,80-4,51)
5,30
(2,00-5,83)
6,20
(2,20-6,71)
7,90
(2,30-8,69)
10,50
(2,50-11,00)
12,00
(2,77-12,70)
Heating capacity nom.(min.-max.)
(kW)
4,80
(2,05-5,28)
5,60
(2,21-6,16)
6.60
(2,39-7,26)
8,20
(2,45-9,02)
11,00
(2,67-11,20)
13,00
(2,96-13,10)
SEER/SCOP
6.15/4.05
7.08/4.06
6.45/4.39
6.29/4.04
6.20/4.00
6.10/4.00
Energy rating cooling/heating
A++/A+
A++/A+
A++/A+
A++/A+
A++/A+
A++/A+
Power consumption cooling
nom.(min.-max.) (kW)
1,24
(0,20-2,1)
1,75
(0,28-2,30)
1,92
(0,35-2,80)
2,46
(0,56-3,40)
3,95
(0,68-4,93)
4,45
(0,75-5,45)
Rated current consumpt. cooling (A)
5,40
7,60
8,30
10,70
17.50
19.72
Power consumption heating
nom.(min.-max.) (kW)
1,15
(0,20-2,10)
1,54
(0,28-2,30)
1,78
(0,35-2,80)
2,27
(0,56-3,40)
3,15
(0,53-3,85)
3,75
(0,60-4,35)
Rated current consumpt. heating (A)
5,00
6,70
7,80
9,80
13.96
16.62
Max. power consumption (kW)
2,10
2,30
2,80
3,40
5.30
5.60
Max. current consumption (A)
10,00
11,00
13,00
16,00
23.5
24.5
Power supply (V~,Hz,Phases)
220-240,50,1
220-240,50,1
220-240,50,1
220-240,50,1
220-240,50,1
220-240,50,1
Sound pressure dB(A)
54
55
56
58
61
61
Sound power dB(A)
61
62
65
65
68
68
Connection wires (mm)
3x1,5+E
3x1,5+E
3x1,5+E
3x1,5+E
3x1,5+E
3x1,5+E
Power supply wires (mm)
2x2,5+E
2x2,5+E
2x2,5+E
2x4,0+E
2x4,0+E
2x4,0+E
Dimensions width/depth/height (mm)
800/545/315
800/545/315
834/655/328
834/655/328
985/808/395
985/808/395
Weight (kg)
34
36
44
46
74
75
Liquid piping diameter (mm/inch)
2×6,35(1/4)
2×6,35(1/4)
3×6,35(1/4)
3×6,35(1/4)
4×6,35(1/4)
5×6,35(1/4)
Gas piping diameter (mm/inch)
2×9,52(3/8)
2×9,52(3/8)
3×9,52(3/8)
3×9,52(3/8)
4×9,52(3/8)
5×9,52(3/8)
Refrigerant type (GWP)*
R32 (675)
Refrigerant quantity (kg)
1.07
1.10
1.25
1.20
2.30
2.30
tCO2 eq.
0,722
0,743
0,844
0,810
1,552
1,552
Meters of precharge gas quantity (m)
15
15
22,5
22,5
30
37,5
Additional charge (g/m)
20
20
20
20
20
20
*These Air Conditioners contain fluorinated greenhouse gases covered by Kyoto protocol.
