Baxi JSGNW - Cassette [Lsgnk(25;35;50)-XM]

5.2.3. CASSETTE [LSGNK(25/35/50)-XM]
Installation space
Please be sure to meet the following installation space requirements when selecting the
installation site:
The distance away from the ceiling and obstacles is shown in the below drawing:
Ensure the installation position is able to take four times of the unit weight. There
should be no increase in noise and vibration.
21
