Baxton Studio Full / Queen Headboard 97093 - Hardware List

Page 2 of 7
Hardware List
3
Queen Bed
Assembly Instructions
F
1
1
1
8
14
H
Note: Extra
holes on top
8
14
H
8
14
H
Assembled the Support Legs (H) to the Long Support (F).
4
M6 x 90mm JCB
x 3
M6 x 70mm JCB
x 8
M6 x 15mm JCB
x 4
Wood Dowel
(10 x 40mm) x 4
Wood Dowel
(8 x 30mm) x 8
Wood Dowel
(6 x 25mm) x 12
Wood Screw
(M4 x 32mm) x 24
Wood Screw
(M4 x 25mm) x 30
Allen Key
x 1
Adjustable
Foot x 3
1 2
4 5 6 7
11
12 1514
Center Rail
Bracket x 2
13
M6 x 40mm JCB
x 20
3
Barrel Nut
x 11
8
Spring
Washer x 4
9
Flat Washer
x 4
10
