Bay-Tek Big Bass Wheel - User Manual

SERVICE MANUAL
PLACE SERIAL NUMBER LABEL HERE

Summary

Factory Contact Information

Welcome and Safety Precautions

Safety Precautions

Essential safety warnings and guidelines for operating the game.

Game Specifications

Weight, Dimensions, and Power Requirements

Details on physical size, weight, and electrical requirements for the game.

Big Bass Wheel Game Setup

Tools, Assembly Notes, and Monitor Installation

Lists tools, safety notes, and initial steps for setting up the game.

Handle, Guard, and Leveling Procedures

Steps for attaching the handle, securing guards, and leveling the game.

How to Play

Game Mechanics and Operation

Explains the game's core gameplay, controls, and scoring system.

Card Swipe System Installation

Installation Options and Menu Settings

How to connect and configure card swipe systems for payment.

Main Menu Functions

Menu Navigation and Basic Settings

How to access menus, reset tickets/credits, and adjust volume.

Advanced Menu Options and Patterns

Configuring ticket patterns, jackpots, and game history.

Ticket Patterns

Pattern Descriptions and Listings

Explains and displays ticket payout estimates for game patterns.

Printer Menu Functions

Printer Status and Receipt Customization

Managing printer settings and personalizing receipt information.

Game Statistics and Secret Menu

Statistics Viewing and Secret Menu Options

Accessing game data and advanced troubleshooting or modification settings.

Game Diagnostic Menu

Diagnostic Information and Troubleshooting

Displaying system status, errors, and input/output signals for diagnosis.

Circuit Board Layout

Identifying Key Components and Connectors

Visual guide to motherboards, I/O boards, and other circuit board elements.

Wiring Diagrams - I;O Aux Board

I;O Aux Board Connections

Illustrates connections for ticket dispensers, coin switches, and card readers.

UCL Connector and Card Swipe Wiring

Details connections for card swipe systems and UCL connector.

Wiring Diagrams - Switches and Controllers

Switch, Motor, and Counter Wiring

Details wiring for various switches, the motor, and game counters.

Menu Button and Bill Acceptor Wiring

Connections for menu buttons and bill acceptor.

Wiring Diagrams - Lighting and Power

Monitor, Power Supply, and LED Wiring

Wiring diagrams for the monitor, power supply, and game lighting systems.

Bobber and Accessory Wiring

Wiring for the bobber, underglow LEDs, and other accessories.

Top of Game Lighting Kit Wiring

Eye Light, Strip, and Wheel Light Wiring

Wiring for all top-mounted and wheel-side LED lighting components.

Speaker Wiring Options

Wiring for Different Game Versions

Explains speaker connection methods for various motherboard revisions.

Motherboard and Software Options

Motherboard Compatibility and Software

Guides on selecting correct motherboards and software versions for game compatibility.

Motherboard Communication Options

Communication Cable Configurations

Details on connecting motherboards to the I/O Aux Board for different game versions.

Game Errors and Diagnostics

Common Error Messages and Causes

Explains errors like 'Door Open,' 'Low Tickets,' and 'Motor Watchdog.'

Troubleshooting Guide - Power and Basic Issues

Power, Monitor, and Bill Acceptor Problems

Diagnosing and resolving issues with power, monitor, and bill acceptor functionality.

Audio, Coin Up, and Ticket Issues

Guides for fixing sound, coin entry, and ticket dispensing malfunctions.

Troubleshooting Guide - Lights and Dispensers

LED Light and Ticket Dispenser Problems

Troubleshooting non-working LEDs and ticket dispenser errors.

Troubleshooting Guide - Payouts and Scoring

Incorrect Payouts and Scoring Errors

Resolving incorrect ticket payouts and problems with game scoring accuracy.

Troubleshooting Guide - Wheel Sensors and Spinning

Wheel Sensor and Spinning Mechanism Issues

Diagnosing issues with the wheel encoder sensor and spin mechanics.

Troubleshooting Guide - Monitor and Game Functions

Monitor Display and Game Function Errors

Troubleshooting monitor display issues and general game function errors.

Troubleshooting Guide - Motor and Solenoid

Motor Assist and Solenoid Operation Problems

Resolving problems with the motor assist and solenoid operation.

Troubleshooting Guide - Meters and Errors

Spin Meter and Monitor Error Messages

Diagnosing spin meter issues and various monitor error messages.

Troubleshooting Guide - Final Checks

Meter, Door, and Motor Watchdog Error Resolution

Addressing meter, door, and motor watchdog errors, plus post-fix checks.

Bill Acceptor Diagnostics and Blanking Plates

Bill Acceptor Power and Settings

Verifying bill acceptor power, cleaning, and checking dipswitch settings.

Power Supply Diagnostics

Verifying Power Output and Connections

Steps to troubleshoot power supply issues and 12-volt output problems.

Door Open Error

Door Switch Function and Troubleshooting

Explains door switch roles and how to diagnose 'Door Open' messages.

Wheel Encoder Sensor

Positioning, Buffer Zones, and Adjustments

How to check wheel position and adjust the encoder sensor bracket for accuracy.

Brake Adjustments

Coast Test and Tension Adjustment

Performing brake tests and adjusting tension for optimal wheel coast time.

Software Updates and Top Tips

Software Update Procedure

How to update the game software using a USB drive.

Useful Game Tips and Tricks

Seven common issues and their solutions for the Big Bass Wheel game.

Puppy Video Wizard and Handle Removal

Monitor Settings Recovery and Handle Removal

Recovering monitor settings and safely removing the game handle for maintenance.

Cleaning and Arm Bracket Maintenance

Window Cleaning and Arm Bracket Checks

Procedures for cleaning game windows and maintaining arm bracket bolts.

Stay Put Kit Installation

Preventing Game Movement with the Kit

How to install the kit to stop the game from moving and its dimensions.

How to Remove Wheel

Step-by-Step Wheel Assembly Removal

Detailed instructions for safely detaching and removing the large game wheel.

Jump Starting the Motherboard

Motherboard Power Issues and Jump Start

Diagnosing motherboard power problems and performing a manual startup.

How to Install a New Monitor

Monitor Replacement Procedure

Step-by-step guide and tools required for installing a new monitor.

Bobber Light Kit Installation

Red LED Kit for Jackpot and Wiring

Installing the bobber red LED kit and its wiring for jackpot signs.

Bobber Light Kit Installation (Continued)

Multiple Game Wiring Setup for Kits

Wiring diagrams for linking multiple games with the bobber light kit.

Pivot Assembly Exploded View

Exploded Diagram of Pivot Parts

Visual breakdown identifying all components of the pivot assembly.

Master Volume Adjustment via Keyboard;Mouse

Volume Adjustment for Software Issues

How to access the desktop and adjust master volume to fix sound problems.

Master Volume Adjustment via Keyboard;Mouse (Continued)

Resolving No Volume Issues

Steps to fix games with no sound by adjusting sound card settings.

Decal Diagram

Locating Game Decals and Graphics

Identifies the placement of all decals on the game's exterior.

Parts Pictures

Identification of Common Game Parts

Visual reference for common game components and hardware.

Identification of Cables and Electronics

Visual reference for various cables, connectors, and electronic parts.

Identification of Kits and Specialized Parts

Visual reference for specialized kits and unique game components.

Parts List

General, Metal, and Cable Parts List

Comprehensive list of general, metal, and cable components with part numbers.

Electronic Parts and Accessories List

Comprehensive list of electronic components and accessories with part numbers.

Decals, Forms, and Ticket Pattern Parts

List of decals, forms, and parts related to ticket patterns.

Circuit Boards and Lighting Parts List

List of circuit boards, power supplies, and lighting components with part numbers.

Repair;Maintenance Log

Logging Maintenance and Repairs

Template for recording game maintenance activities and part orders.

Technical Support and Warranty

Obtaining Technical Assistance

Information on how to contact Bay Tek for technical support and advice.

Warranty Coverage and Claims Process

Details on product warranty period, terms, and how to file a claim.

Bay-Tek Big Bass Wheel Specifications
