Table 1: Electromagnetic emissions
This equipment is intended for use in the electromagnetic environment specified below.
The user of the equipment should assure that it is used in such an environment
Emissions Test Compliance
Radiated emissions
EN 55011
Complies (Group B, Group 1)
Conducted emissions
CISPR 11 / EN 55011
Complies
AC Power-line harmonics
IEC 61000-3-2
Complies
AC Power-line Flicker
IEC 61000-3-3
Complies
Table 2: Electromagnetic immunity
This equipment is intended for use in the electromagnetic environment specified below.
The user of the equipment should assure that it is used in such an environment.
Immunity Test IEC 60601 test level Compliance level
Electrostatic discharge
IEC 61000-4-2
+ 8 kV Contact, HCP & VCP
+2 kV, +4 kV, +8 kV, + 15 kV Air
+ 8 kV Contact, HCP & VCP
+2 kV, +4 kV, +8 kV, + 15 kV Air
Radiated RF Immunity
IEC 61000-4-3
80 MHz - 2.7 GHz, 10 V/m,
80% 1 kHz AM
80 MHz - 2.7 GHz, 10 V/m,
80% 1 kHz AM
Electrical Fast
Transient/Burst
IEC 61000-4-4
+ 2 kV (100 kHz rep rate)
AC mains
+ 1 kV (100 kHz rep rate) I/O > 3m
+ 2 kV (100 kHz rep rate)
AC mains
+ 1 kV (100 kHz rep rate) I/O > 3m
Surge Immunity
IEC 61000-4-5
+0.5 kV & + 1 kV line-line,
AC mains
+0.5 kV, + 1 kV, + 2 kV lineground,
AC mains
+0.5 kV & + 1 kV line-line,
AC mains
+0.5 kV, + 1 kV, + 2 kV lineground,
AC mains
Conducted RF
immunity
IEC 61000-4-6
150 kHz to 80 MHz, 3 Vrms, 80%
1 kHz AM, power and I/O
6 Vrms (+modulation) for
ISM frequencies
150 kHz to 80 MHz, 3 Vrms, 80%
1 kHz AM, power and I/O
6 Vrms (+modulation) for
ISM frequencies
Power Frequency
H-field
IEC 61000-4-8
50 and 60 Hz, 30 A/m,
x-, y-, and z- axes
50 and 60 Hz, 30 A/m,
x-, y-, and z- axes
Voltage Dips,
Interrupts
IEC 61000-4-11
100% reduction for 0.5 cycles
100% reduction for 1.0 cycle
30% reduction for 25/30 cycles
100% reduction for 250/300 cycles
100% reduction for 0.5 cycles
100% reduction for 1.0 cycle
30% reduction for 25/30 cycles
100% reduction for
250/300
cycles
Guidance and Manufacturer's Declarations
To Next Page
