BDCOM GP3600-08 GPON Hardware Installation Manual
- 16 -
Figure 3-8 Connecting the 1000M optical port and other devices
To use the electrical port, you can connect the electric port and other Ethernet devices
with the direct-through or cross cable through the UTP port of the GPON access device.
In this case, the corresponding optical port cannot be used. The numbering order of the
pins in the UTP port is the same as the console port.
Figure 3- 9 RJ-45 connector of the console port
Because 4 1000Base-T ports of BDCOM GP3600-08 GPON support the MDI/MDIX
auto-identification of the cable, BDCOM GP3600-08 GPON can adopt five classes of
direct-through/cross network cables when it connects other Ethernet terminals.
Table 3- 3 Definition of the pins of the 1000M RJ45 port
No.
Pin Name
Symbol
Remarks
1
Sending the normal phase of the data
TXD1+
Output
2
Sending the paraphase of the data
TXD1-
Output
