Bdcom S1010-8P-120 User Manual

Disclaimer
Please note that the manual is for reference only. It does not cons
tute a legal contract or a commitment between
BDCOM and any person or en
ty. Although ever y effor t has been made to ensure all the informa on is
correct ,inaccuracies or typographical errors may s
occur. In no event shall BDCOM be responsible or liable, directly or
indirectly, for any damage or loss caused or alleged to be caused by or in connec
on with the manual.
BDCOM reser ves the right to alter, update and other wise change the informa
on contained in the manual from me to
me without no e.
Introduction
Overview
S1010-8P-120/S1006-4P-65 are Power Over Ethernet switch. The PoE por ts can automa ally detect and
supply power with those IEEE 802.3af/at compliant Powered Devices (PD). The power is transmi
ed along with
data by one single cable allowing you to expand your network where there are no power lines or outlets and
which allow you to expand devices such as AP, IP Cameras or IP Phones, etc.
The PoE Switch have VLAN func
on that improve the network environment and reduces network maintenance
costs.
Port Feature
Model
10/100Mbps RJ45 Port
PoE Port
PoE Standard
S1010-8P-120
10
Port1~8
IEEE802.3af/at
S1006-4P-65
6
Port1~4
Product Appearance
Front panel
The Front Panel of the S1010-8P-120 consists of 10-Por t 10/100M Auto-Nego
a on Ethernet R
J45 Por t. The LED indicators are also on located on the panel.
DIP Switch
The DIP switch in located in the le panel.
Standard: the factory default mode, can normally communicate between port 1~10.
VLAN: 1-8 port can be isolated each other, but 1-8 port can connect to 9/10 port a
er open VLAN model to stop
broadcast storm Which can increase forwarding rate of frame.
1

Bdcom S1010-8P-120 Specifications

General

Brand	Bdcom
Model	S1010-8P-120
Category	Switch
Language	English
