Desktop Installation
Install the Switch on a desktop, please a ach these cushioning rubber feet provided on the
bo
om at each corner of the Switch in case of the external vibra on. Allow adequate space for
ven
a on between the device and the objects around it.
The S1010-8P-120 Desktop Installa
on
The S1006-4P-65 Desktop Installa on
Wall-mounted installation
In the first two fixed screw on the wall as shown in the figure below
Aim at the two fixed hole switches, and the machine smoothly on the screw
( S1010-8P-120)
Default
VLAN
CCTV
5
