Extend: Up to 250m PoE distance.it allows you to expand you network via Ethernet cable to where there is no power
Line or outlet but where you want to fix device such as IP Cameras.
LED indicator
LED Color Func
on
PWR
Green
Off: No Power supply.
Light: Indicates the switch has power.
LNK/ACT Green
Off: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
Established at 10/100Mbps.
Blink: Indicates that the Switch is ac
vely sending or
Receiving data over that port.
PoE Orange
Off: No PoE powered device (PD) connected.
Light: There is a PoE PD connected to be port, which
Supply power successfully.
Blink: Indicates port abnormal power supply.
The Front Panel of the S1006-4P-65 consists of 6-Por t 10/100M Auto-Nego a on Ethernet R J45 Por ts, The LED
indicators also on located on the panel.
DIP Switch
The DIP switch is located in the le panel.
Default mode: when open default mode ,the poe switch can normally communicate between port 1~6
CCTV mode: 1-4 port can be isolated each other .but 1-4 port can connect to 5, 6 port a
er open CCTV to stop
broadcast storm which can increase forwarding rate of frame. The CCTV mode, allows you to expand you network via
Ethernet cable to where no power line or outlet .
Note: A
er change the mode, in order to the corresponding configura on take effect.the PoE switch need to restart
manually restart the PoE switch.
2
5 6
PoE
4*10/100Mbps PoE Port
2*10/100Mbps Port
CCTV
OFF
ON
PoE
DATA
10/100M
BDCOM S1006-4P-65
DIP Switch
Power
