LED indicator
LED
Color
Func on
PWR Orange
O: No Power supply.
Light: Indicates the switch has power.
DATA Green
O: No device is connected to the corresponding port.
Light: Indicates the link through that port is successfully
established at 10/100Mbps.
Blink: Indicates that the Switch is ac
vely sending or
receiving data over that port.
PoE Orange
O: No PoE powered device (PD) connected.
Light: There is a PoE PD connected to be port, which
supply power successfully.
Blink: Indicates port abnormal power supply.
The rear panel of S1010-8P-120 indicates AC inlet power socket .
Rear Panel
The rear panel of S1006-4P-65 indicates AC inlet power socket .
3
Grounding Column
Power Socket
max
Power Socket
Grounding Column
Rear Panel
