ASSEMBLY
STEP 12. INSTALL GLASS TOP ON CABINET
With the help of another person, carefully place the (C12) Cabinet Glass on the (C1) Cabinet,
ensuring the glass’s cutout is on the same side as the (C9) “T” Bracket.
Note: Wires can be routed into the cabinet using the hole located near the
(C9) T-Bracket. Route wires as needed, then place (C12) Cabinet Glass and align flush
to cabinet.
2 PERSON TASK
C1
C12
C12
C9
