SEQUEL 6051/52
LIFT DESK
3
Step 3 - Secure the keypad cord into the groove using 6 cord clips H6 and 6 wood screws H2. Connect
keypad cord into the Control Module Port (labeled HS) and bundle the slack with the Hook & Loop Tie.
H2 x 6
H6 x 6
Groove for Keypad Cord
Hook & Loop Tie
