Operation
MAB 480 20
Operation
Activating/deactivating magnetic clamp
Activating magnetic clamp
CAUTION
► Switch on the magnetic clamp only when the machine is
standing on a magnetic substrate to avoid overheating of the
magnet.
Turn on switch (22). The indicator light in switch (22) comes
on.
Check the magnet clamping force at the magnet indica-
tor (24). When the magnet clamping force is sucient, the
MAGNET POWER indicator light (24) is green. If the MAG-
NET POWER indicator light (24) is red, there is not sucient
magnet clamping force available.
CAUTION
► The maximum magnet clamping force is only available after
switching on the motor.
Deactivating magnetic clamp
Secure the machine at the handle to prevent the machine
from slipping o the surface.
Turn o switch (22). The indicator light in switch (22) goes
out.
Switching machine ON/OFF
Turn the machine ON at the ON/OFF switch (21) with the
green button (I) and OFF with the red button (O).
NOTE
► The machine can only be switched on when the magnetic
clamp has been switched on.
► Allow a severely overheated machine to run on at no-load
speed for approx. 2 minutes to let it cool down.
► The machine switches o automatically in the event of a
power failure or if the magnetic clamp is switched o.
