Becker AR6201 - Environmental Qualification RT6201

AR6201 - RT6201 - RCU6201 - AR6203
Page 1-16 DV 14307.03 Issue 1 09/2013
Condition
Section
Cat.
Description
Audio Freq. Conducted
Susceptibility
18.0
B
DC installations with
battery of significant
capacity
Induced Signal Susceptibility
19.0
AC
Primary power DC or AC,
400Hz
Radio Frequency
Susceptibility
20.0
RW
Interim high intensity
radiated fields
Emission of Radio Frequency
Energy
21.0
B
Equipment where interference
should be controlled to a
tolerable level
Lightning Induced Transients
Susceptibility
22.0
A1E3X
Pin test waveform A, level 3
Cable bundle test waveform
E, level 3
Lightning Direct Effects
23.0
- N/A
Icing
24.0
- N/A
Electrostatic Discharge
25.0
A
Equipment operated in an
aerospace environment
Fire, Flammability
26.0
- N/A
1.9 Environmental Qualification RT6201
Under environmental test condition in accordance with the procedures set
forth in EUROCAE/RTCA Document ED-14F/DO-160F the following performance
has been demonstrated.
Condition
Section
Cat.
Description
Temperature and Altitude
4.0
C4
Ground Survival Low
Temperature
4.5.1
C4
-55 deg C
Short-Time Operating Low
Temperature
-40 deg C
Low Operating Temperature -40 deg C
High Ground Survival
Temperature
4.5.2
+85 deg C
High Short-Time Operating
Temp.
+70 deg C
High Operating Temp. +55 deg C
In-flight Loss of Cooling 4.5.5 - No forced cooling required
Altitude 4.6.1 C4 35000 ft
