Becker AR6201 - Aircraft with Intercom System

AR6201 - RT6201 - RCU6201 - AR6203
Page 2-52 DV 14307.03 Issue 1 09/2013
2.9.8 Aircraft with Intercom System
Installation Setup for Aircraft with Intercom System
Sub-Menu
Function: / Selection
“SPKR VOLUME SOURCE BOTH
“CONFIGURATION” “SWAP MIKE IC” : Disabled
“IN/OUT CFG1”: “MICROPHONE 1” : STD1_MIKE
“MICROPHONE 2” : NONE
“BOTH MIKES” : Enabled
“HEADPHONE 1” : Enabled
“SPEAKER” : Disabled
“IN/OUT FG2” “MICROPHONE 1” : STD1_MIKE
“MICROPHONE 2” : NONE
“BOTH MIKES” : Enabled
“HEADPHONE 1” : Enabled
“SPEAKER” : Enabled
Remarks The same configuration applies for balanced
and unbalanced wiring.
