P. [Unit] Setting
range
Description Ex works
5E1 Profile FE14 (radio channel 4)
Selection of the input profile for input FE14 (profile depends on input function con-
figured)
This function is only possible when setting P.802:1.
01
5E4
0..1
Direction FE14 (radio channel 4)
For setting the direction with two-way traffic control for this input.
0: Inside
1: Outside
This function is only possible when setting P.802:1 and P.892:1.
0
610
11..29
Function FE1 (BDC-XXX M2)
Selection of the input function for input FE1
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1.
0
611 Parameter FE1 (BDC-XXX M2)
Selection of the input profile for input FE1 (parameter depends on input function
configured)
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1.
00
614
0..1
Direction FE1 (BDC-XXX M2)
For setting the direction with two-way traffic control for this input.
0: Inside
1: Outside
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1 and P.802:1.
0
620
11..29
Function FE2 (BDC-XXX M2)
Selection of the input function for input FE2
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1.
0
621 Parameter FE2 (BDC-XXX M2)
Selection of the input profile for input FE2 (parameter depends on input function
configured)
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1.
00
624
0..1
Direction FE2 (BDC-XXX M2)
For setting the direction with two-way traffic control for this input.
0: Inside
1: Outside
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1 and P.802:1.
0
630
11..29
Function FE3 (BDC-XXX M2)
Selection of the input function for input FE3
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1.
0
631 Parameter FE3 (BDC-XXX M2)
Selection of the input profile for input FE3 (parameter depends on input function
configured)
This function is only possible in combination with BDC‑XXX M2 when setting
P.801:1.
00
42
