Product overview
2.4 Types
The CPU module can be equipped with different software options for control software. The operating system
is limited to "Windows Embedded Compact 7". The TwinCAT automation software transforms a CX9020
system into powerful PLC and Motion Control system that can be operated with or without visualization.
Further system interfaces (pre-installed in the factory) or fieldbus connections can be added to the basic
CPU module.
The CX9020 is available in the following types:
Table1: CX9020 (1 GHz 1 core)
Module no
operating
system
Windows
Embedded
Compact 7
no
TwinCAT
TwinCAT 2
PLC runtime
TwinCAT 2
NC runtime
TwinCAT 3
XAR
CX9020-0100 X X
CX9020-0110 X X - - -
CX9020-0111 X - X - -
CX9020-0112 X - - X -
CX9020-0115 X - - - X
Note
Software Images
A list of the different software images can be found in the Software Documentation.
CX9020 11Version: 1.5
