Product overview
EL28xx-xxxx 27Version: 2.2
2.4.2 Technical data
Technical data EL2872 EL2872-0010
digital outputs 16
Rated load voltage 24 V
DC
(-15% / +20%), max. 1A per connection pin
Load type ohmic, inductive, lamp load
Non-reactive outputs
yes (see notice [}13])
-
Max. output current 0.5A (short-circuit-proof) per channel
Short circuit current 0.6 ... 2.0A
Breaking energy < 150mJ/channel
Current consumption from the E-
bus
typ. 130mA
Electrical isolation 500V (E-bus/field voltage)
Bit width in the process image 16 output bits
Configuration no address or configuration settings required
Conductor connection 20-pin contact strip
Weight approx. 55g
Permissible ambient temperature
range during operation
0 °C ... +55 °C
Permissible ambient temperature
range during storage
-25 °C ... +85 °C
Permissible relative humidity 95%, no condensation
Dimensions (W x H x D) approx. 15mm x 100mm x 70mm (connected width: 12mm)
Installation [}63]
on 35 mm mounting rail according to EN 60715
Vibration / shock resistance conforms to EN 60068-2-6 / EN 60068-2-27,
see also installation instructions for terminals with increased
mechanical load capacity [}67]
EMC immunity/emission conforms to EN 61000-6-2 / EN 61000-6-4
Protection class IP20
Installation position variable
Approval CE
cULus [}73]
ATEX [}75]
