Beckhoff EL34 Series User Manual

Commissioning
EL34xx142 Version: 1.5
Assignment of variable output values across all channels
Values (dec),
Entry in PDOs: PMX
Variant Value In Index
1-3 REAL
[0xF700:11, 0xF700:12,
0xF700:13]
Values (dec),
Entry in PDOs: PMX
Variant Value In
Index 4 ULINT
[0xF700:14]
Meaning Unit Description
1107 (= 1024 + 83) - PQF Max - Maximum power quality factor in the last inter-
val
- 1124 (= 1024 + 100)* Eptot_fund mWh Balanced total fundamental wave active energy
- 1125 (= 1024 + 101)* EPtot_fund pos mWh Received total fundamental wave active energy
- 1126 (= 1024 + 102)* EPtot_fund neg mWh Supplied total fundamental wave active energy
- 1127 (= 1024 + 103)* Eptot_fund _inter-
vall
mWh Balanced total fundamental wave active energy
in the last interval
- 1128 (= 1024 + 104)* EPtot_fund pos_in-
tervall
mWh Received total fundamental wave active energy
in the last interval
- 1129 (= 1024 + 105)* EPtot_fund neg_in-
tervall
mWh Supplied total fundamental wave active energy
in the last interval
- 1130 (= 1024 + 106)* EStot_fund mWh Total fundamental wave apparent energy
- 1131 (= 1024 + 107)* EStot_fund pos mWh
- 1132 (= 1024 + 108)* EStot_fund neg mWh
- 1133 (= 1024 + 109)* EStot_fund _inter-
vall
mWh Total fundamental wave apparent energy in the
last interval
- 1134 (= 1024 + 110)* EStot_fund pos_in-
tervall
mWh
- 1135 (= 1024 + 111)* EStot_fund neg_in-
tervall
mWh
- 1136 (= 1024 + 112)* EQtot_fund mWh Balanced total fundamental wave reactive en-
ergy
- 1137 (= 1024 + 113)* EQtot_fund pos mWh Inductive total fundamental wave reactive en-
ergy
- 1138 (= 1024 + 114)* EQtot_fund neg mWh Capacitive total fundamental wave reactive en-
ergy
- 1139 (= 1024 + 115)* EQtot_fund _inter-
vall
mWh Balanced total fundamental wave reactive en-
ergy in the last interval
- 1140 (= 1024 + 116)* EQtot_fund pos_in-
tervall
mWh Inductive total fundamental wave reactive en-
ergy in the last interval
- 1141 (= 1024 + 117)* EQtot_fund neg_in-
tervall
mWh Capacitive total fundamental wave reactive en-
ergy in the last interval
1154 (= 1024 + 130)* - Ptot_fund W Total fundamental wave active power
1155 (= 1024 + 131)* - Ptotavg_fund W Total fundamental wave average active power
during last interval
1156 (= 1024 + 132)* - Ptotmin_fund W Total fundamental wave minimum active power
in the last interval
1157 (= 1024 + 133)* - Ptotmax_fund W Total fundamental wave maximum active power
in the last interval
1160 (= 1024 + 136)* - Stot_fund VA Total fundamental wave apparent power
1161 (= 1024 + 137)* - Stotavg_fund VA Total fundamental wave average apparent
power during last interval
1162 (= 1024 + 138)* - Stotmin_fund VA Total fundamental wave minimum apparent
powerin the last interval
1163 (= 1024 + 139)* - Stotmax_fund VA Total fundamental wave maximum apparent
power in the last interval
1166 (= 1024 + 142)* - Qtot_fund Var Total fundamental wave reactive power
1167 (= 1024 + 143)* - Qtotavg_fund Var Total fundamental wave avarage reactive
power during last interval
1168 (= 1024 + 144)* - Qtotmin_fund Var Total fundamental wave minimum reactive
power during last interval
1169 (= 1024 + 145)* - Qtotmax_fund Var Total fundamental wave maximum reactive
power during last interval
Values with star* are only available in the EL3453.
