Commissioning
EL34xx216 Version: 1.5
Index (hex) Name Meaning Data type Flags Default
F802:28 Unbalance Guard
Max Error
Upper limit value for an error message due to voltage
imbalance
REAL32 RW EL3423, EL3453
0,000000
(0,000000e+000)
EL3443
3,000000
(3,000000e+000)
Index F803 PMX Time Settings
Index (hex) Name Meaning Data type Flags Default
F803:0 PMX Time Settings Max. subindex UINT8 RO 0x13 (19
dec
)
F803:11 Measurement Mode permitted values: UINT32 RW 0x00000000 (0
dec
)
0
F803:12 Measurement Interval Time in seconds to automatic restart of the measure-
ment and statistics interval
UINT32 RW 0x00000000 (0
dec
)
F803:13 Actual System Time Shows the current system time of the terminal. Write
access to the object is possible in order to change
the system time.
STRING RW
Index F804 PMX Settings Neutral Current
Index (hex) Name Meaning Data type Flags Default
F804:0 PMX Settings Neutral
Current
Max. subindex UINT8 RO 0x14 (20
dec
)
F804:12 Current Transformer
Ratio
The transmission ratio of the current transformer
used can be entered here.
REAL32 RW 1,000000
(1,000000e+000)
F804:13 Current Transformer
Delay
A possible time delay of the current transformers in
milliseconds can be entered here.
REAL32 RW 0,000000
(0,000000e+000)
F804:14 Current Range Selection of the current measuring range:
100: 100mA
1000: 1A
5000: 5A
UINT32 RW 1 A (1000)
Index F804 PMX Settings Neutral Current
Index (hex) Name Meaning Data type Flags Default
F804:0 PMX Settings Neutral
Current
Max. subindex UINT8 RO 0x14 (20
dec
)
F804:12 Measurement Mode permitted values: UINT32 RW 0x00000000 (0
dec
)
0
F804:13 Measurement Interval Time in seconds to automatic restart of the measure-
ment and statistics interval
UINT32 RW 0x00000000 (0
dec
)
F804:14 Actual System Time Shows the current system time of the terminal. Write
access to the object is possible in order to change
the system time.
STRING RW
