Beckhoff EL34 Series User Manual

Commissioning
EL34xx 215Version: 1.5
Index (hex) Name Meaning Data type Flags Default
F802:0 PMX Guard Settings Max. subindex UINT8 RO 0x28 (40
dec
)
F802:11 Frequency Guard Min
Error
Lower limit value for a frequency error message REAL32 RW 47,000000
(4,700000e+001)
F802:12 Frequency Guard Min
Warning
Lower limit value for a frequency warning message REAL32 RW 49,500000
(4,950000e+001)
F802:13 Frequency Guard
Max Warning
Upper limit value for a frequency warning message REAL32 RW 50,500000
(5,050000e+001)
F802:14 Frequency Guard
Max Error
Upper limit value for a frequency error message REAL32 RW 52,000000
(5,200000e+001)
F802:15 Neutral Current Guard
Min Error
Lower limit value for an error message of the neutral
conductor current
REAL32 RW EL3423, EL3443
0,000000
(0,000000e+000)
EL3453
-1,050000
(-1,050000e+000)
F802:16 Neutral Current Guard
Min Warning
Lower limit value for a warning message of the neu-
tral conductor current
REAL32 RW EL3423, EL3443
0,000000
(0,000000e+000)
EL3453
-1,000000
(-1,000000e+000)
F802:17 Neutral Current Guard
Max Warning
Upper limit value for a warning message of the neu-
tral conductor current
REAL32 RW EL3423, EL3443
0,006000
(6,000000e-003)
EL3453
1,000000
(1,000000e+000)
F802:18 Neutral Current Guard
Max Error
Upper limit value for an error message of the neutral
conductor current
REAL32 RW EL3423, EL3443
0,030000
(3,000000e-002)
EL3453
1,050000
(1,050000e+000)
F802:19 Active Power Guard
Min Error
Lower limit value for an active power error message REAL32 RW 0,000000
(0,000000e+000)
F802:1A Active Power Guard
Min Warning
Lower limit value for an active power warning mes-
sage
REAL32 RW 0,000000
(0,000000e+000)
F802:1B Active Power Guard
Max Warning
Upper limit value for an active power warning mes-
sage
REAL32 RW 0,000000
(0,000000e+000)
F802:1C Active Power Guard
Max Error
Upper limit value for an active power error message REAL32 RW 0,000000
(0,000000e+000)
F802:1D Apparent Power
Guard Min Error
Lower limit value for an apparent power error mes-
sage
REAL32 RW 0,000000
(0,000000e+000)
F802:1E Apparent Power
Guard Min Warning
Lower limit value for an apparent power warning
message
REAL32 RW 0,000000
(0,000000e+000)
F802:1F Apparent Power
Guard Max Warning
Upper limit value for an apparent power warning
message
REAL32 RW 0,000000
(0,000000e+000)
F802:20 Apparent Power
Guard Max Error
Upper limit value for an apparent power error mes-
sage
REAL32 RW 0,000000
(0,000000e+000)
F802:21 PQF Guard Min Error Lower limit value for a power quality factor error mes-
sage
REAL32 RW 0,050000
(5,000000e-002)
F802:22 PQF Guard Min
Warning
Lower limit value for a power quality factor warning
message
REAL32 RW 0,800000
(8,000000e-001)
F802:23 PQF Guard Max
Warning
Upper limit value for a power quality factor warning
message
REAL32 RW 1,000000
(1,000000e+000)
F802:24 PQF Guard Max Error Upper limit value for a power quality factor error mes-
sage
REAL32 RW 1,000000
(1,000000e+000)
F802:25 Unbalance Guard Min
Error
Lower limit value for an error message due to voltage
imbalance
REAL32 RW 0,000000
(0,000000e+000)
F802:26 Unbalance Guard Min
Warning
Lower limit value for a warning message due to volt-
age imbalance
REAL32 RW 0,000000
(0,000000e+000)
F802:27 Unbalance Guard
Max Warning
Upper limit value for a warning message due to volt-
age imbalance
REAL32 RW EL3423, EL3453
0,000000
(0,000000e+000)
EL3443
2,000000
(2,000000e+000)
