Beckhoff EL34 Series User Manual

Commissioning
EL34xx 217Version: 1.5
6.7.4.3 Configuration data (vendor-specific)
Index 80nF PMX vendor data (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
80nF:0 PMX Vendor data Max. subindex UINT8 RO 0x1C (28
dez
)
80nF:11 Calibration Voltage
Offset
Value in V REAL32 RW 0,000000
(0,000000e+000)
80nF:12 Calibration Voltage
Gain
Factor (without unit) REAL32 RW 1,000000
(1,000000e+000)
80nF:13 Calibration Voltage
Phase Offset
Value in milliseconds REAL32 RW 0,000000
(0,000000e+000)
80nF:14 Calibration Current
Offset
Value in A REAL32 RW 0,000000
(0,000000e+000)
80nF:15 Calibration Current
Gain
Factor (without unit) REAL32 RW 1,000000
(1,000000e+000)
80nF:16 Calibration Current
Phase Offset
Value in milliseconds REAL32 RW 0,000000
(0,000000e+000)
80nF:17 Calibration Current 1
Offset
Value in A REAL32 RW 0,000000
(0,000000e+000)
80nF:18 Calibration Current 1
Gain
Factor (without unit) REAL32 RW 1,000000
(1,000000e+000)
80nF:19 Calibration Current 1
Phase Offset
Value in milliseconds REAL32 RW 0,000000
(0,000000e+000)
80nF:1A Calibration Current 2
Offset
Value in A REAL32 RW 0,000000
(0,000000e+000)
80nF:1B Calibration Current 2
Gain
Factor (without unit) REAL32 RW 1,000000
(1,000000e+000)
80nF:1C Calibration Current 2
Phase Offset
Value in milliseconds REAL32 RW 0,000000
(0,000000e+000)
6.7.4.4 Input data
Index 60n0 PMX status (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n0:0 PMX Status Max. subindex UINT8 RO 0x10 (16
dec
)
60n0:01 Voltage Sign Bit Indicates the sign of the current sine wave voltage:
1 = U > 0V
0 = U < 0V
BOOLEAN RO 0x00 (0
dec
)
60n0:02 Overvoltage Maximum measurable voltage is exceeded. BOOLEAN RO 0x00 (0
dec
)
60n0:03 Overcurrent Maximum measurable current is exceeded. BOOLEAN RO 0x00 (0
dec
)
60n0:04 Inaccurate Voltage The measured voltage value is smaller than the value
entered in CoE object "F800:15 Inaccurate Threshold
Voltage".
BOOLEAN RO 0x00 (0
dec
)
60n0:05 Inaccurate Current The measured current value is smaller than the value
entered in CoE object "F800:16 Inaccurate Threshold
Current".
BOOLEAN RO 0x00 (0
dec
)
60n0:06 Voltage Guard Warn-
ing
A warning limit of the voltage monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
60n0:07 Voltage Guard Error An error limit of the voltage monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
6000:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
Index 60n1 PMX Basic (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n1:0 PMX Basic Max. Subindex UINT8 RO 0x12 (18
dec
)
60n1:11 Voltage RMS value of the voltage in V REAL32 RO 0x00000000 (0
dec
)
60n1:12 Current RMS value of the current in A REAL32 RO 0x00000000 (0
dec
)
