Beckhoff EL34 Series User Manual

Commissioning
EL34xx162 Version: 1.5
Index (hex) Name Meaning Data type Flags Default
F802:28 Unbalance Guard
Max Error
Upper limit value for an error message due to voltage
imbalance
REAL32 RW EL3423, EL3453
0,000000
(0,000000e+000)
EL3443
3,000000
(3,000000e+000)
Index F803 PMX Time Settings
Index (hex) Name Meaning Data type Flags Default
F803:0 PMX Time Settings Max. subindex UINT8 RO 0x13 (19
dec
)
F803:11 Measurement Mode permitted values: UINT32 RW 0x00000000 (0
dec
)
0
F803:12 Measurement Interval Time in seconds to automatic restart of the measure-
ment and statistics interval
UINT32 RW 0x00000000 (0
dec
)
F803:13 Actual System Time Shows the current system time of the terminal. Write
access to the object is possible in order to change
the system time.
STRING RW
6.7.2.3 Configuration data (vendor-specific)
Index 80nF PMX vendor data (for ch.1, n = 0; ch.2, n = 1; ch.3, n = 2)
Index (hex) Name Meaning Data type Flags Default
80nF:0 PMX Vendor data Max. subindex UINT8 RO 0x16 (22
dec
)
80nF:11 Calibration Voltage
Offset
Value in V REAL32 RW 0x00000000 (0
dec
)
80nF:12 Calibration Voltage
Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80nF:13 Calibration Voltage
Phase Offset
Value in milliseconds REAL32 RW 0x00000000 (0
dec
)
80nF:14 Calibration Current
Offset
Value in A REAL32 RW 0x00000000 (0
dec
)
80nF:15 Calibration Current
Gain
Factor (without unit) REAL32 RW 0x3F800000
(1065353216
dec
)
80nF:16 Calibration Current
Phase Offset
Value in milliseconds REAL32 RW 0x00000000 (0
dec
)
6.7.2.4 Input data
Index 60n0 PMX status (n = 0, 1, 2)
Index (hex) Name Meaning Data type Flags Default
60n0:0 PMX Status Max. subindex UINT8 RO 0x10 (16
dec
)
60n0:01 Voltage Sign Bit Indicates the sign of the current sine wave voltage:
1 = U > 0V
0 = U < 0V
BOOLEAN RO 0x00 (0
dec
)
60n0:02 Overvoltage Maximum measurable voltage is exceeded. BOOLEAN RO 0x00 (0
dec
)
60n0:03 Overcurrent Maximum measurable current is exceeded. BOOLEAN RO 0x00 (0
dec
)
60n0:04 Inaccurate Voltage The measured voltage value is smaller than the value
entered in CoE object "F800:15 Inaccurate Threshold
Voltage".
BOOLEAN RO 0x00 (0
dec
)
60n0:05 Inaccurate Current The measured current value is smaller than the value
entered in CoE object "F800:16 Inaccurate Threshold
Current".
BOOLEAN RO 0x00 (0
dec
)
60n0:06 Voltage Guard Warn-
ing
A warning limit of the voltage monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
60n0:07 Voltage Guard Error An error limit of the voltage monitor has been
breached.
BOOLEAN RO 0x00 (0
dec
)
6000:10 TxPDO Toggle The TxPDO toggle is toggled by the slave when the
data of the associated TxPDO is updated.
BOOLEAN RO 0x00 (0
dec
)
