Commissioning
EL34xx 201Version: 1.5
Index 1A20 Total TxPDO-Map Advanced
Index (hex) Name Meaning Data type Flags Default
1A20:0 Total TxPDO-Map Ad-
vanced
PDO Mapping TxPDO 33 UINT8 RO 0x08 (8
dec
)
1A20:01 SubIndex 001 1. PDO Mapping entry (object 0xF602 (PMX Grid Ad-
vanced), entry 0x11 (Max Voltage Harmonic Distor-
tion))
UINT32 RO 0xF602:01, 1
1A20:02 SubIndex 002 2. PDO Mapping entry (object 0xF602 (PMX Grid Ad-
vanced), entry 0x12 (Max Current Harmonic Distor-
tion))
UINT32 RO 0xF602:02, 1
1A20:03 SubIndex 003 3. PDO Mapping entry (object 0xF602 (PMX Grid Ad-
vanced), entry 0x13 (Max Current Distortion Factor))
UINT32 RO 0x0000:00, 13
1A20:04 SubIndex 004 4. PDO Mapping entry (object 0xF602 (PMX Grid Ad-
vanced), entry 0x14 (Voltage Unbalance))
UINT32 RO 0xF602:10, 1
1A20:05 SubIndex 005 5. PDO Mapping entry (object 0xF602 (PMX Total
Advanced), entry 0x11 (Max Voltage Harmonic Dis-
tortion))
UINT32 RO 0xF602:11, 32
1A20:06 SubIndex 006 6. PDO Mapping entry (object 0xF602 (PMX Total
Advanced), entry 0x12 (Max Current Harmonic Dis-
tortion))
UINT32 RO 0xF602:12, 32
1A20:07 SubIndex 007 7. PDO Mapping entry (object 0xF602 (PMX Total
Advanced), entry 0x13 (Max Current Distortion Fac-
tor))
UINT32 RO 0xF602:13, 32
1A20:08 SubIndex 008 8. PDO Mapping entry (object 0xF602 (PMX Total
Advanced), entry 0x14 (Voltage Unbalance))
UINT32 RO 0xF602:14, 32
Index 1A21 Total TxPDO-Map Total Active
Index (hex) Name Meaning Data type Flags Default
1A21:0 Total TxPDO-Map To-
tal Active
PDO Mapping TxPDO 34 UINT8 RO 0x04 (4
dec
)
1A21:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A21:02 SubIndex 002 2. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x12 (Active Energy))
UINT32 RO 0xF603:12, 64
1A21:03 SubIndex 003 3. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x13 (Active Positive Energy))
UINT32 RO 0xF603:13, 64
1A21:04 SubIndex 004 4. PDO Mapping entry (object 0xF603 (PMX Total
Active), entry 0x14 (Active Negative Energy))
UINT32 RO 0xF603:14, 64
Index 1A22 Total TxPDO-Map Apparent
Index (hex) Name Meaning Data type Flags Default
1A22:0 Total TxPDO-Map Ap-
parent
PDO Mapping TxPDO 35 UINT8 RO 0x04 (4
dec
)
1A22:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A22:02 SubIndex 002 2. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x12 (Apparent Energy))
UINT32 RO 0xF605:12, 64
1A22:03 SubIndex 003 3. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x13 (Apparent Positive Energy))
UINT32 RO 0xF605:13, 64
1A22:04 SubIndex 004 4. PDO Mapping entry (object 0xF605 (PMX Total
Apparent), entry 0x14 (Apparent Negative Energy))
UINT32 RO 0xF605:14, 64
Index 1A23 Total TxPDO-Map Reactive
Index (hex) Name Meaning Data type Flags Default
1A23:0 Total TxPDO-Map
Reactive
PDO Mapping TxPDO 36 UINT8 RO 0x04 (4
dec
)
1A23:01 SubIndex 001 1. PDO Mapping entry (32 bits align) UINT32 RO 0x0000:00, 32
1A23:02 SubIndex 002 2. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x12 (Reactive Energy))
UINT32 RO 0xF607:12, 64
1A23:03 SubIndex 003 3. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x13 (Reactive Positive Energy))
UINT32 RO 0xF607:13, 64
1A23:04 SubIndex 004 4. PDO Mapping entry (object 0xF607 (PMX Total
Reactive), entry 0x14 (Reactive Negative Energy))
UINT32 RO 0xF607:14, 64
