Mounting and wiring
EL34xx 57Version: 1.5
Terminal point Description Comment
Name No.
L1 1 Phase L1 Connections for the voltage measurement
Note the Warnings [}54] above " Caution: Risk
of electric shock! "
L2 2 Phase L2
L3 3 Phase L3
N 4 Neutral conductor N
(internally connected to terminal point 8)
IL1 5 Consumer at phase L1 Connections for the current transformers. Note
the Warnings [}54] above " Caution: Risk of
electric shock!"
IL2 6 Consumer at phase L2
IL3 7 Consumer at phase L3
N 8 Neutral conductor N
(internally connected to terminal point 4)
