Mounting and wiring
EL34xx60 Version: 1.5
Terminal point Description Comment
Name No.
I
L1
1 Phase L1 current measurement input Connections for the current
transformers. Note the Warnings
[}54] above " Caution: Risk of electric
shock!"
I
L2
2 Phase L2 current measurement input
I
L3
3 Phase L3 current measurement input
I
N
4 Neutral conductor current measurement input
(star point)
I
L1
‘ 5 Phase L1 current measurement output
I
L2
‘ 6 Phase L2 current measurement output
I
L3
‘ 7 Phase L3 current measurement output
I
N
‘ 8 Neutral conductor current measurement
output (star point)
L1 1‘ Phase L1 Connections for the voltage
measurement
Note the Warnings [}54] above "
Caution: Risk of electric shock!
2‘ n.c.
L3 3‘ Phase L3
N 4‘ Neutral conductor
(internally connected with terminal point 8‘)
5‘ n.c.
L2 6‘ Phase L2
7‘ n.c.
N 8‘ Neutral conductor
(internally connected with terminal point 4‘)
