RCD TESTING
RCD Types Tested
RCD Type
[5]
AC
[1]
G
[2]
√
AC S
[3]
√
A
[4]
G √
A S √
Note:
[1] AC – Responds to ac
[2] G – General, no delay
[3] S – Time delay
[4] A – Responds to pulsed signal
[5] RCD test inhibited for V >265 ac
RCD tests permitted only if the selected current, multiplied by earthing resistance, is <50V.
Test Signals
RCD Type Test Signal Description
AC
(sinusoidal)
The waveform is a sinewave starting at zero crossing, polarity
determined by phase selection (0 ° phase starts with low to
high zero crossing, 180 ° phase starts with high to low zero
crossing). The magnitude of the test current is I
P
n x Multiplier
for all tests.
A
(half wave)
The waveform is a half wave rectified sinewave starting at
zero, polarity determined by phase selection (0 ° phase starts
with low to high zero crossing, 180 ° phase starts with high
to low zero crossing). The magnitude of the test current is
2.0 x I
P
n (rms) x Multiplier for all tests for I
P
n = 0.01A. The
magnitude of the test current is 1.4 x I
P
n (rms) x Multiplier for
all tests for all other I
P
n ratings.
RCD Types Tested (
P
T)
Test Function
RCD Current Selection
10 mA 30 mA 100 mA 300 mA 500 mA 1000
mA
[1]
var
[2]
X ½, 1 √ √ √ √ √ √ √
X 5 √ √ √
Ramp √ √ √ √ √ √ √
Auto √ √ √
Note:
Mains voltage 100 V – 265 V ac, 50/60 Hz
[1] Type AC RCDs only.
[2] Type A RCDs are limited to 700 mA, not available for Type B RCDs.
