5
UNPACKING AND INSPECTION
Your shipping carton should include:
• ProInstall-75
• Test lead set
• ProInstall-TL-UK (LC38 AMP-MFT, mains test cord)
• Alligator clips
• Test probe
• ProInstall-TL-KIT (Remote test probe and probe tips)
• ProInstall-CC (Soft case with carrying strap)
• TL-75 ( Fused test probe, red/blue/green with lantern spring, cap and tip cover)
• Zero-Adapter
• Statement of calibration
• Batteries
• Quick reference guide
• Carry strap for neck/waist
• CD-ROM (User manual)
If any of the items are damaged or missing, return the complete package to the place of
purchase for an exchange.
OPERATING THE TESTER
Using the Rotary Switch
Use the rotary switch to select the type of test you want to perform.
Understanding the Pushbuttons
Use the pushbuttons to control operation of the tester, select test results for viewing, and
scroll through selected test results.
19
12
11
7
8
9
10
2
1
5 6 18
3
4
13 14
15
16
17
