24 UB-Xa User Manual
MSB LSB 14-bit Parameter Name Range Scope Notes
3 8 392 EnvelopesModChannel1A 0~16383 patch
3 9 393 EnvelopesModChannel1Delay 0~16383 patch
3 10 394 EnvelopesModChannel2A 0~16383 patch
3 11 395 EnvelopesModChannel2Delay 0~16383 patch
3 12 396 EnvelopesPedalR 0~16383 patch
4 0 512 OscillatorsOSC1PWAmount 0~16383 patch
4 1 513 OscillatorsOSC1Transpose 0~16383 patch Signed Number, Midpoint is 8192.
4 2 514 OscillatorsOSC2PWAmount 0~16383 patch
4 3 515 OscillatorsOSC2Transpose 0~16383 patch Signed Number, Midpoint is 8192.
4 4 516 OscillatorsMode 0~3 patch Bitmask: OSC2 sync on~OSC2 sync o (01) OSC2 f-env on~OSC2 f-env o (10)
4 5 517 OscillatorsOSC1State 0~7 patch Bitmask: OSC1 full~OSC1 o (001) OSC1 VCO LFO 180~OSC1 VCO LFO 0 (010)
OSC1 PWM LFO 180~OSC1 PWM LFO 0 (100)
4 6 518 OscillatorsOSC1Shapes 0~2 patch Enumeration: Osc1 pulse (0), Osc1 saw (1), Osc1 tri (2),
4 7 519 OscillatorsOSC2State 0~2 patch Enumeration: Osc2 half (0), Osc2 full (1), Osc2 o (2),
4 8 520 OscillatorsOSC2Shapes 0~2 patch Enumeration: Osc2 pulse (0), Osc2 saw (1), Osc2 tri (2),
4 9 521 OscillatorsOSC1PWTrimL 0~255 global
4 10 522 OscillatorsOSC1PWTrimR 127~255 global
4 11 523 OscillatorsOSC2PWTrimL 0~255 global
4 12 524 OscillatorsOSC2PWTrimR 127~255 global
4 13 525 OscillatorsModDepth 6~48 global
4 14 526 OscillatorsPWMDepth 0~255 global
4 15 527 OscillatorsPWMOsetShift 0~255 global
4 16 528 OscillatorsChaos 0~63 global
4 17 529 OscillatorsVPOError 0~31 global
4 18 530 OscillatorsDriftSpeed 0~63 global
4 19 531 OscillatorsVPOErrorChaos 0~63 global
4 20 532 OscillatorsOscAutoInitF 0~127 global
4 21 533 OscillatorsFEnvRange 1~63 global
5 0 640 FilterFrequency 0~16383 patch
5 1 641 FilterResonance 0~16383 patch
5 2 642 FilterModulation 0~16383 patch
5 3 643 FilterNoise 0~16383 patch
5 4 644 FilterModes 0~3 patch Bitmask: Filter track on~Filter track o (01) 4 pole lter~2 pole lter (10)
5 5 645 FilterResonanceTrim 0~255 global
5 6 646 FilterResonanceTrim4Pole 0~255 global
5 7 647 FilterFrequencyRange 0~63 global
5 8 648 FilterZero2pOset 0~48 global
5 9 649 FilterZero4pOset 0~48 global
5 10 650 FilterModulationRange 0~127 global
5 11 651 FilterEnvLinearity 0~63 global
5 12 652 FilterEnvChaos 0~31 global
5 13 653 FilterLFORange 0~127 global
5 14 654 FilterChaos 0~63 global
5 15 655 FilterDriftSpeed 0~63 global
5 16 656 FilterTrackOset 0~63 global
5 17 657 FilterPedalRange 0~96 global
5 18 658 FilterVPOError 0~63 global
5 19 659 FilterVPOErrorChaos 0~63 global
5 20 660 FilterInitFreq 0~127 global
6 0 768 ModMatrixBus1Amount 0~16383 patch Signed Number, Midpoint is 8192.
6 1 769 ModMatrixBus2Amount 0~16383 patch Signed Number, Midpoint is 8192.
