b) When pressed a second time the SENSITIVITY can be adjusted (SENS will light up in the display).

This governs the sensitivity of the dynamic high cut filter and how it reacts to the input signal. The value

ranges from 0 to 100.

When the LEFT key is pressed only the settings for the left channel are edited.

Use the RIGHT key to select the right audio channel.

+ If you wish to process the left and right audio channels simultaneously (COUPLE mode), press

both LEFT & RIGHT keys together. In couple mode both key LEDs light up. Whenever you edit

one of the two audio channels and then switch to couple mode, the parameters of the active

channel will be copied to the other; i.e. if you press LEFT before RIGHT, left will be copied to

right.

The EXCITER key has three functions:

a) PROCESS, (PROC will light up) when pressed once the intensity of the Exciter function can be

adjusted ranging from 0 to 100.

b) Pressed a second time the TUNE parameter can be set (kHz will light up). The TUNE control sets

the lower cut-off frequency of the Exciter function. The cut-off frequency can be adjusted within a

range of 4 to 12 kHz.

c) The third function is reached by pressing the EXCITER key for more than 2 seconds. The upper

frequency band is then muted. This is indicated by a full LED bar that flashes on and off (GR HI). This

function is useful when you want to monitor the processing of the ULTRAMIZERPRO. Alternatively the

unit can also be used as a crossover to generate a subwoofer signal for instance.

The SUPERBASS key has three functions:

a) PROCESS, when pressed once the intensity of the SuperBass function can be adjusted ranging

from 0 to 100 (PROC will light up).

b) Pressed a second time the TUNE parameter can be set (Hz will light up). Here the TUNE control

sets the upper cut-off frequency of the SuperBass function. The cut-off frequency can be adjusted

within a range of 50 to 150Hz.

c) Again the third function is reached by pressing the SUPERBASS key for more than 2 seconds. The

lower frequency band is now muted. This is indicated by a full GR LO LED bar that flashes on and off.

+ When the EXCITER and SUPERBASS keys are pressed simultaneously, the crossover frequency,

between  the lower and higher bands of the multiband compressor  can be adjusted from

20Hz to 20kHz.

The IN/OUT key enables you to bypass the DSP1400P. The green LED lights up as soon as the

ULTRAMIZERPRO is activated.

Whenever a setting has been changed the PRESET key starts to blink slowly, indicating that a preset

has been changed but not stored. When the PRESET key is pressed once the current preset number

is shown in the numeric display. When the PRESET key is pressed again the current preset number

starts flashing, you can then select any of the 50 memory locations. Press a third time to save the

edited program to a user preset as shown in the display.

+ When the IN/OUT and PRESET keys are pressed simultaneously the ULTRAMIZERPRO enters

the MIDI menu, where all MIDI settings can be edited.
