6.2 Specifications
Analog Inputs
Connectors XLR and 1/4" jack
Type RF filtered, servo balanced input
Impedance 50 kOhms balanced, 25 kOhms unbalanced
Nominal Operating Level -10dBV to +4dBu
Max. Input Level +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level
Analog Outputs
Connectors XLR and 1/4" jack
Type Electronically servo-balanced output stage
Impedance 60 Ohms balanced, 30 Ohms unbalanced
Max. Output Level +16 dBu at +4 dB nominal level, +2 dBV at -10 dBV nominal level
System specifications
Bandwidth 20Hz to 20kHz, +0/-0.5dB
Frequency Response 0.35Hz to 200kHz, +0/-3dB
Noise >-95dBu, unweighted, 22Hz to 22kHz
THD 0.008 % typ. @ +4dBu, 1kHz, Gain 1
0.04 % typ. @ +16dBu, 1kHz, Gain 1
IMD 0.01 % typ. SMPTE
Crosstalk <-100dB, 22Hz to 22kHz
MIDI Interface
Type 5-Pin-DIN-Socket IN / OUT / THRU
Implementation Refer to MIDI Implementation Chart in Chapter 8
Digital Processing
Converters 20-bit Sigma-Delta, 64/128-times Oversampling
Sampling Rate 46kHz
Display
Type 2 ½-digit numeric LED-Display
Power Supply
Mains Voltages
USA/Canada ~ 115 V AC, 60Hz
U.K./Australia ~ 240 V AC, 50Hz
Europe ~ 230 V AC, 50Hz
General Export Model ~ 100-120 V AC, ~ 200-240 V AC, 50-60Hz
Fuse 100-120 V AC: 250 mA (slow-blow)
200-240 V AC: 125 mA (slow-blow)
Power Consumption 10 Watts
Mains Connection Standard IEC receptacle
Physical
Dimensions (H * W * D) 1 3/4 (44.5 mm) * 19 (482.6 mm) * 7 1/2 (190.5 mm)
Net Weight 2 kg
Shipping Weight 3.2 kg
BEHRINGER is constantly striving to maintain the highest professional standards. As a result of these efforts, modifications may be made
from time to time to existing products without prior notice. Specifications and appearance may differ from those listed or shown.
