14 XENYX X1222USB User Manual
Channels 9/10, 11/12
Stereo line inputs
Type 2 x ¼" TRS connector, unbalanced
Impedance approx. 40 kΩ @ 0 dB Gain
Gain range -20 dB to +20 dB
Max. input level +22 dBu @ 0 dB Gain
CD/Tape In
Type RCA connectors
Impedance approx. 10 kΩ
Max. input level +22 dBu
EQ Mono Channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
Low cut 80 Hz, 18 dB/oct.
EQ Stereo Channels
Low 80 Hz / ±15 dB
Mid 2.5 kHz / ±15 dB
High 12 kHz / ±15 dB
MON/FX Send
Type ¼" TS connector, unbalanced
Impedance approx. 120 Ω
Max. output level +22 dBu
Aux Returns
Type ¼" TRS connector, unbalanced
Impedance approx. 10 kΩ
Max. input level +22 dBu
Main Outputs
Type XLR, electronically balanced
Impedance approx. 240 Ω balanced
approx. 120 Ω unbalanced
Max. output level +28 dBu
Headphone Output
Type ¼" TRS connector, unbalanced
Max. output level +19 dBu / 150 Ω (+25 dBm)
CD/Tape Out
Type RCA connectors
Impedance approx. 1 kΩ
Max. output level +22 dBu
DSP Texas Instruments
Converter 24-bit Sigma-Delta
64/128-times oversampling
Sampling rate 40 kHz
USB
Audio Stereo In/Out
Connector Type B
Converter 16-bit
Sample Rate 48 kHz
Main Mix System Data
Noise
Main mix @ -∞, -99 dB
Channel fader -∞ -101 dB A-weighted
Main mix @ 0 dB, -84 dB
Channel fader -∞ -87 dB A-weighted
Main mix @ 0 dB, -80 dB
Channel fader @ 0 dB -82 dB A-weighted
Power Supply
Mains Voltage 100 - 240 V~, 50 - 60 Hz
Power consumption 40 W
Fuse T 1.6 A H 250 V
Mains connection Standard IEC receptacle
Physical
Dimensions (W x D x H) approx. 14.56 x 13 x 3.54"
approx. 370 x 330 x 90 mm
Weight (net) approx. 9.3 lbs.
approx. 4.22 kg
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all channels on main mix;
channels 1/3 as far left as possible, channels 2/4 as far right as possible. Reference = +6 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or illustrated.
