20 XENYX X1622USB/X1832USB/X2222USB/X2442USB User Manual
Main mix system data
2
Noise
Main mix @ -oo,
Channel fader @ -oo -101 dB
-100 dB (X2442USB)
Main mix @ 0 dB,
Channel fader @ -oo -93 dB
-96 dB (X1622USB)
-87 dB (X2442USB)
Main mix @ 0 dB,
Channel fader @ 0 dB -81 dB
-83 dB (X1622USB)
-80 dB (X2442USB)
Power supply
Mains voltage 100 to 240 V~, 50/60 Hz
Power consumption 50 W (X1622USB)
50 W (X1832USB)
50 W (X2222USB)
50 W (X2442USB)
Fuse 100 - 240 V ~: T 1.6 A H 250 V
Mains connection Standard IEC receptacle
Physical
X1622USB
Dimensions (H x W x D) approx. 3 ⁄ x 11 ⁄ x 13 ⁄"
approx. 97 x 301 x 351 mm
X1832USB / X2222USB
Dimensions (H x W x D) approx. 3 ⁄ x 16 ⁄ x 14 ⁄"
approx. 97 x 408 x 367 mm
X2442USB
Dimensions (H x W x D) approx. 5 ⁄ x 16 ½ x 17 ¼"
approx. 136 x 418 x 438 mm
Weight (net)
X1622USB approx. 3.3 kg
X1832USB approx. 4.7 kg
X2222USB approx. 4.8 kg
X2442USB approx. 5.9 kg
Measuring conditions:
1: 1 kHz rel. to 0 dBu; 20 Hz - 20 kHz; line input; main output; unity gain.
2: 20 Hz - 20kHz; measured at main output. Channels 1 - 4 unity gain; EQ flat; all channels on main mix;
channels 1/3 as far left as possible, channels 2/4 as far right as possible. Reference = +6 dBu.
BEHRINGER is constantly striving to manintain the highest professional standards. As a result of these efforts,
modifications may be made from time to time to existing products without prior notice. Specifications and
appearance may differ from those listed or liiustrated.

Behringer XENYX X1832USB Specifications

General

Channels	18
USB Interface	Yes
Phantom Power	+48V
Faders	60mm
EQ	3-band on all channels
Effects	Yes, 24-bit multi-FX processor
Aux Sends	2
Outputs - Main	2 x XLR, 2 x 1/4"
USB	1 x Type B
Headphone Output	1 x 1/4"
Mic Preamps	6
