State Description
Fast flashing Eject USB/SD card.
NOTE
Fast flashing continues for a couple of seconds after
ejecting the USB/SD card.
2.3.2. Purple
State Description
Constant on Operating system is booting up.
Every 0.5 seconds
on/off
The unit is on standby and no iX Runtime or CODESYS project is
running.
Fast flashing for 5
seconds
USB/SD card project (iX or CODESYS) update successful.
2.3.3. Blue
State Description
Every 0.5 seconds
on/off
The iX project is running.
Every 0.5 seconds,
short flash
CODESYS project is running.
Every 0.5 seconds,
alternately short
and long flash
Both iX and CODESYS running.
NOTE
If the LED alternatively flashes Red to Blue to Purple, the wrong image type is
installed. Please reinstall correct image.
