Split type air conditioner / User Manual
15 / 196 EN
2.1 Indoor unit display
C
Note: Different models have different front panels and display windows. Not all the display
codes describing below are available for the air conditioner you purchased. Please check
the indoor display window of the unit you purchased.
Illustrations in this manual are for explanatory purposes. The actual shape of your indoor unit may be
slightly different. The actual shape shall prevail.
(A) (B)
Front panel
Louver
Power cable (some units)
Remote control
Remote control holder
(some units)
Display window
“fresh“ when Fresh or HygieneMax (if any) feature is activated (some units)
“defrost“ when defrost feature is activated.
“run“ when the unit is on.
“timer“ when TIMER is set.
“
“ when Wireless Control feature is activated (some units)
“
“ Displays temperature, operation feature and error codes:
•
“ “ for 3 seconds when:
•
TIMER ON is set (if the unit is OFF, “ “ remains on when TIMER
ON is set)
•
FRESH, HygieneMax, SWING, TURBO, ECO, or SILENCE feature is turned on
“
“ for 3 seconds when:
•
TIMER OFF is set
•
FRESH, HygieneMax, SWING, TURBO, ECO, or SILENCE feature is turned off
•
“ “ when defrosting
•
“ “ when 8°C heating feature is turned on (some units)
•
“ “ when GoClean feature is turned on (For Inverter split type)
when unit is SelfClean+ (For Fixed-speed type)
fresh defrost run timer
Functional filter
(On back of main filter - some units)
Display Code
Meanings
2 Unit specifications and features
