Split type air conditioner / User Manual
16 Specifications
Model name
Indoor unit BBVHM 090 BBVHM 120 BBVHM 180 BBVHM 240
Outdoor unit BBVHM 091 BBVHM 121 BBVHM 181 BBVHM 241
Outdoor unit Resistance Class IP24 IP24 IP24 IP24
High Pressure Pipe Diameter (mm) 6.35mm (1/4in) 6.35mm (1/4in) 6.35mm (1/4in) 9.52mm (3/8in)
Low Pressuer Pipe Diameter (mm) 9.52mm (3/8in) 12.7mm (1/2in) 12.7mm (1/2in) 15.9mm (5/8in)
Max. elevation (m) 10 10 20 20
Max. pipe length (m) 25 25 30 30
Additional Gas Quantity (g/m) 15 15 15 30
Power Supply Cord specification (mm
2
) 1.5x3 1.5x3 1.5x3 2.5x3
Indoor & Outdoor Connection Cord (mm
2
) 1.5x4 1.5x4 1.5x4 1.5x4
Indoor Unit (WxHxD) mm 729x292x200 802x295x200 971x321x228 1082x337x234
Outdoor Unit (WxHxD) mm 720x495x270 720x495x270 805x554x330 890x673x342
Indoor Unit Net Weight (kg) 8.0 9.0 12.0 14.0
Outdoor Unit Net Weight (kg) 23.0 22.5 33.0 41.5
Note:
1. Specifications are standard values calculated based on rated operating conditions, They will vary in
difference work condition.
2. Our company has quick technical imporvments. There will be prior notice for any change of technical
data. Please read nameplate on the air-conditioner.
