DURAFLO™ 18 GPM PUMPING STATIONS
24 Belanger, Inc.® * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL375
Maintenance
Drive Belt Replacement and Tightening
6) Check back belt tension with Goodyear tension gauge (1GAUGE905, shown below).
NOTE: NOTE THE PUMP STATION USES BX STYLE BELTS, A 4.2” SMALL PULLEY AND
860-2500 RPM MOTOR. THE PULLEY SPAN IS 14”. THESE NUMBERS CROSS
REFERENCE TO 7.2 LB. BELT TENSION FOR NEW BELTS AND 4.9 LB. FOR USED
BELTS ON THE GOODYEAR CHART SUPPLIED WITH THE TENSION GAUGE.
Span Scale: set this o-ring at 14”
Deflection Force Scale
5V, 5VX
4.4- 6.7
1750-3000
8.8
3001
-
4000
500
-
1749
5.6
10.2
13.2
8.5
15.2
B, B
X
3.4
-
4.2
860-2500
4.9
15.2
2501-4000
7.2
