Belanger DuraFlo - Pumping Station Float Valve Seal Replacement Kit (#105884)

DURAFLO™ 18 GPM PUMPING STATIONS
26 Belanger, Inc.® * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681 1MANUL375
Maintenance
Pumping Station Float Valve Seal Replacement Kit (#105884)
The following Kit Includes the Parts Shown Below:
Qty.
Description
1
Teflon™ Cup
1
Standard Disc
1
Top Follower
Required Tools
Description
Example
Remarks
1/2” Open-End Box Wrench
Needle-Nosed Pliers
12” Adjustable Wrench
Removing the Existing Stem Assembly
1) Remove the Float-Rod by removing the Cap Screw from the Float-Rod Connector using a
1/2” wrench.
2) Remove the Down-Spout.
Float
-
Rod
Down
-
Spout
Cap Screw
