DURAFLO™ 18 GPM PUMPING STATIONS
32
Belanger, Inc.® * PO BOX 5470 * Northville, MI 48167-5470 * Ph (248) 349-7010 * Fax (248) 380-9681
1MANUL375
Maintenance
Pumping Station Float Valve Seal Replacement Kit (#105884)
Reassemble the Valve with a Rebuilt Stem Assembly
3) Re-install the Swivel Yoke and Lock Nut, and then tighten them both into place.
4) Re-install the Jam Nut and the Lift, and then tighten them both into place.
5) Re-install the Lever, Pins and Cotter Pins.
