3522.5-0000010 РЭ
74
Tables of fuses and relay assignment, presented in figure 2.18.3, are stuck from outside to
the upper plastic cover 2 (figure 2.18.1) from the windscreen side.
Information on fuses and relay assignment as well as fuse ratings are given in ta-
bles 2.6 and 2.7.
Table 2.6 – Assignment of switching unit fuses
Fuse designa-
tion
Fuse assignment
(protected electric circuit)
Fuse rating
FU1 Reserve 20А
FU2 Lower beam of right road headlight 7,5А
FU3 Lower beam of left road headlight 7,5А
FU4 Road headlights upper beam 15А
FU5 Reserve 20А
FU6 Rear screen washer and wiper 15А
FU7 Power supply to conditioner electric motor 25А
FU8 “Road-train” lights and cab light 7,5А
FU9 Signal beacon 7,5А
FU10 Rear working lights (a pair of outer lights) 15А
FU11 Front working lights (on the roof) 15А
FU12 Not used 15А
FU13 Not used 30А
FU14 Rear working lights (a pair of inner lights) 15А
FU15 Radioset (stereo-recorder) 15А
FU16 Horn 15А
FU17 Front working lamps (on handgrip) 15А
FU18 Braking lights 15А
FU19
Socket to connect trailed agricultural equipment and
a portable lamp.
15А
FU20
Signal from terminal “D” of the alternator to systems
of FLL, RLL and OPU of the HLL control and to
electic socket 6 (figure 2.22.2)
30А
FU21 Front screen washer and wiper 15А
FU22 Warning indication 15А
FU23
Power supply to consumers, staying on when the
starter and instrument switch is in position “instru-
ments are on”
25А
FU24 Left parking lights 7,5А
FU25 Right parking lights and instruments illumination 15А
FU26 CECS, IEP and EECS 15А
FU27
Test instruments, sensors of speed, RPTO and fuel
volume
7,5А
FU28 Annunciation of tractor and trailer turning 7,5А
FU29 Remote cutout of accumulator battery 15А
FU30
Power supply to coil of instrument illumination and
parking lights relay
20А
