MIPP
Release
01
01/12
13
Figure 7: CU single module – Components
1 – Cable inlet with bracket for tie wraps
2 – Ground screw
3 – Fixing screw
4 – RJ45 Keystone jacks
5 – Fixing screw
Figure 8: RJ45 Keystone jack
1 – Latch
2 – Inlet for patch cable
3 – Inlet for an installed cable
The following cable types can be used:
Cat 5E (shielded and unshielded)
Cat 6 (shielded and unshielded)
Cat 6A (shielded and unshielded)
Cat 7 (shielded)
The following connector types can be used:
RJ45
1
5
4
3
2
