Belden Hirschmann MIPP - 4 Technical Data

22
MIPP
Release 01 01/12
4 Technical data
 General technical data
 Adapters and Keystone jacks
 Scope of delivery
Dimensions
W × D × H
Single module, front side
Single module, rear
Double module, front side
Double module, rear
Housing wall
Spacer with divider
Spacer without divider
30 mm × 133 mm × 146 mm
30 mm × 133 mm × 167 mm
60 mm × 133 mm × 146 mm
60 mm × 133 mm × 167 mm
6 mm × 133 mm × 167 mm
30 mm × 133 mm × 167 mm
30 mm × 133 mm × 167 mm
Weight LC/SC single module
CU single module
Double module
Housing wall
Spacer with divider
Spacer without divider
138 g
580 g
275 g
170 g
140 g
71 g
Operating
temperature
−20 °C … +70 °C
Protection classes LC/SC module
CU module
IP 40
IP 20
Adapter Suitable cables Suitable connectors
LC Duplex adapter Cable types:
- OF loose tube cable
- Tight buffered cable
- Semi-tight buffered cable
LC connector according to
IEC 61754-20
SC Duplex adapter Cable types:
- OF loose tube cable
- Tight buffered cable
- Semi-tight buffered cable
SC connector according
to IEC 61754-4, -19
RJ45 Keystone jack Cable types:
- Cat 5E (shielded and unshielded)
- Cat 6 (shielded and unshielded)
- Cat 6A (shielded and unshielded)
- Cat 7 (shielded)
RJ45 connector
Device Scope of delivery
Modular Industrial Patch Panel
(MIPP)
Device with modules according to order
Description and operating instructions
Return note
