Figure 1: MIPP with 3 single modules and 1 double module
1 – Cable entry with bracket for tie wraps
2 – Cable entry with cable gland M16
3 – Cable entry with cable gland M16
4 – Cable entry with cable gland M20
5 – Screw for fixing the module
6 – Screw for fixing the adapter
7 – LC double module with LC Duplex adapter
8 – LC single module with LC Duplex adapter
9 – SC single module with SC Duplex adapter
10 – CU single module with RJ45 Keystone jacks
11 – Bolt for fixing the housing
12 – Housing
13 – Bolt for fixing the housing
