LMU230(-S/-F)
Technical data
Electrical data
AC 100...240V 50/60Hz
Nominal voltage
Nominal voltage range
Power consumption
Wire/transformer sizing
Auxiliary switch
LMU230-S
Connection: Motor
Auxiliary switch LMU230-S
Torque
Direction of rotation
Manual override
Angle of rotation
Running time
Sound power level
Position indication
Protection class
Degree of protection
EMC
Low voltage directive
Mode of operation
Ambient temperature
Non-operation temperature
Humidity test
Maintenance
Dimensions (LxWxH)
Shaft length: LMU230(-S)
Shaft : LMU230(-S)
LMU230-F
Weight
AC 85...265V
1.5W @ running / 0.5W @ holding
3.5VA
Cable 1m, 3x0.75mm
2
Functional data
5Nm
Selectable by switch
Max. 95
°
, adjustable by mechanical stops
150s for 95
°
Max. 35dB(A)
Mechanical, remote visible
Working conditions
II (totally insulated)
IP54 in any direction
CE according to 89/336/EEC
Type 1 to EN 60730-1
-30...+50
°
C
-40...+80
°
C
95% RH, non-condensing (EN 60730-1)
Maintenance-free
Dimensions / weight
See 'Dimensions'
8x8mm
Min. 37mm
LMU230-F Min. 20mm
6...20mm
Approximately 550g
Dimensions [mm]
Cable 1m, 3x0.75mm
2
1161620
74
16
8
22
94
41
28.5
100.5
0
3
6
6
2.5
116
74
16
22
94
41
66
LMU230-F
LMU230(-S)
1 SPDT, 1mA...3(0.5)A, AC 250V , adjustable
CE according to 73/23/EEC
Gearing latch disengaged by pushbutton, self-resetting
•ΓFor operation of air control dampers in HVAC system
•ΓTorque: 5Nm
•ΓNominal voltage: AC 100...240V
•ΓControl: Open/Close or 3-point
